Electric Power/Hydraulic/Water Energy Command center

Electric Power/Hydraulic/Water Energy Command center

Construction background
With the rapid development of information technology, the amount of information to be processed by the command and dispatch center is also increasing. How to enable operators to process multiple different data applications "quickly, simultaneously and by comparison" and realize information interaction (content, intercom, information) and cooperation between operators at the same time has become a necessary function of modern information interaction management platform. In the face of hundreds of scheduling computers and management servers in the command center, it is obvious that the man-machine dialogue management mode in the past, where man and machine are in the same space and one person and one machine, has been unable to meet the demand of multi-scene, multi-application and multi-network segment rapid collaborative office.



The construction of the target
Network monitoring of the construction of the center for a new generation of network monitoring center, using the latest display technology, integration of centralized monitoring technology, the advanced display technology, etc., to build the most advanced centralized network management monitoring center, make it become the all business operations, centralized monitoring, safety network centralized maintenance, emergency command and scheduling, the external image display comprehensive demonstration center
Improve the production, operation and maintenance and service environment, set up a unified standard of network service support image and realize the network service support quality service window. Build a modern integrated operation and maintenance monitoring center that integrates operation and maintenance, emergency command and dispatch, business exhibition and external visit, and become a window to show the overall style of government, enterprises and institutions and a powerful platform for command and dispatch. The main functions are as follows:
1. Aggregation and integration of the whole platform, sharing, interaction and collaboration between the system information data servers and workstations
2. Operate different application systems or information platforms at the same time to realize resource sharing and arbitrary allocation according to their own permissions
3. The seats can cooperate with each other, including single screen, multi-screen and cross-department cooperation, and the required resources can be pushed to the seats during operation
4. Large screen comparison and analysis of various information or data synchronously or asynchronously, the display system has no black screen switching, and has the ability of fast screen switching
5. The system has good usability and emergency mechanism, humanized, operable, convenient user interface and emergency plan
6. Ensure the security of data and the stability of the system, without equipment downtime, and can work 7x 24 hours

Husion solution
HUSION ELECTRONICS KVM collaborative management platform for digital visualization breaks the single structure of each system existing in the previous construction, supports multi-user multi-level permission and multi-operating system application, and provides a highly integrated, humanized and intelligent management platform for the core of command and scheduling.
Lake, electronic professional digital visual collaboration management platform, KVM solution across a network, across different systems, applications, cross-sectoral, many kinds of data application, how to make the operator to "fast, at the same time, compare" handle multiple different data application, at the same time to realize the information interaction between the operator (content, intercom, information) and collaboration related affairs. Can synthesize all kinds of image resources, application resources, data resources in accordance with the prescribed collaborative process and seat control authority for unified management, operation, scheduling, shorten the response time, improve the overall response capacity.
Considering the power/water/water energy command center of the stability of the KVM collaborative management platform is the key of the project construction, so the design of the system USES lake, double link terminals, double network transmission system, the hot standby system structure of double server, realize the collaborative management platform KVM double backup protection, any single point terminal, network, server failure will not affect the normal use of the system, the system robustness is extremely high.

System function
Visual KVM collaborative management platform can realize the hot key mode of seat staff using a set of local keyboard.
Push the data information that needs to be put into the display terminal to the big screen or other cooperative seats with one key to realize data collaborative processing and collaboration Multi-network integration, cross-network operation, for the business system, many and different functions, the lack of centralized seat management system for unified monitoring, command and scheduling. By collecting the video, audio, key and mouse of different network segment computers, the KVM collaboration system realizes the takeover of the computer and completely sets aside the limitation of network segment
Operating across systems, convenient for different operators free scheduling from different operating systems (Windows, Android, MAC, Linux, Unix, Kylin) business platform data content.
Seat across the multi-screen operation, to achieve one person multi-machine efficient data management, analysis, comparison, real-time operation of multiple sets of data business system, to achieve a set of keyboard, mouse seamless across different screens;
Seat authority management, the operator account as the center to achieve permission distribution, content push access, audio and video interaction, can be through the hierarchical user management mode, the corresponding administrator to set different access and management authority.

Plan advantage
1. Full light and heat preparation
Fiber KVM cooperative management platform has a perfect redundancy backup mechanism. All input nodes, output nodes, transmission links and servers can adopt dual optical thermal backup/dual network thermal backup and power supply thermal backup. It greatly improves the disaster tolerance of the system to ensure that the system can run normally even in the face of various emergency failures
2. Visual scheduling
Full video preview, large screen echo, drag and drop screen, bring good operation experience; The operation is visible, the node status can be inquired, the peripheral equipment "vital signs" can be presented, the system management is convenient, reduce the maintenance cost
Open interfaces
4K uhd resolution signal, no black screen switching, fast screen switching ability, support various signals, including interfaces such as dvi-i, dvi-d, VGA, HDMI, SDI, 3g-sdi, DP and so on. The system should support multiple resolutions, including VGA, XGA, 720P, 1080P, 2K, 4K.
4. Man-machine separation
The operator is separated from the server and unified management of the server ensures data security, saves command space, reduces environmental heat, improves office command environment, and realizes centralized management of local maintenance, remote control and remote operation of the computer room
5. Group management
Business/operation/command hall monitoring operation seat according to the online business structure, different business island, function island grouping management, combined with authority management, orderly organization of online business, not only to achieve effective data sharing, and properly avoid data leakage

Application topology
